*Corresponding Author:
V. K. Vyas
Department of Pharmaceutical Chemistry, Institute of Pharmacy, Nirma University, Ahmedabad-382 481, India
E-mail: [email protected]
Date of Submission 20 June 2011
Date of Revision 24 February 2012
Date of Acceptance 26 February 2012
Indian J Pharm Sci, 2012, 74 (1): 1-17

Abstract

Major goal of structural biology involve formation of protein-ligand complexes; in which the protein molecules act energetically in the course of binding. Therefore, perceptive of protein-ligand interaction will be very important for structure based drug design. Lack of knowledge of 3D structures has hindered efforts to understand the binding specificities of ligands with protein. With increasing in modeling software and the growing number of known protein structures, homology modeling is rapidly becoming the method of choice for obtaining 3D coordinates of proteins. Homology modeling is a representation of the similarity of environmental residues at topologically corresponding positions in the reference proteins. In the absence of experimental data, model building on the basis of a known 3D structure of a homologous protein is at present the only reliable method to obtain the structural information. Knowledge of the 3D structures of proteins provides invaluable insights into the molecular basis of their functions. The recent advances in homology modeling, particularly in detecting and aligning sequences with template structures, distant homologues, modeling of loops and side chains as well as detecting errors in a model contributed to consistent prediction of protein structure, which was not possible even several years ago. This review focused on the features and a role of homology modeling in predicting protein structure and described current developments in this field with victorious applications at the different stages of the drug design and discovery.

Keywords

Drug discovery, GPCRs, homology modeling, ligand design, loop structure prediction, model validation, sequence alignment

Introduction

The prediction of the 3D structure of a protein from its amino acid sequence remains a basic scientific problem. This can often achieved using different types of approaches and the first and most accurate approach is “comparative” or “homology” modeling[1]. Homology modeling methods use the fact that evolutionary related proteins share a similar structure[2,3]. Determination of protein structure by means of experimental methods such as X-ray crystallography or NMR spectroscopy is time consuming and not successful with all proteins, especially with membrane proteins[4]. Currently, experimental structure determination will continue to increases the number of newly discovered sequences which grows much faster than the number of structures solved. Currently, 79,356 experimental protein structures are available in the Protein Data Bank (PDB)[5], http://www.rcsb.org/pdb (February 2012). Homology modeling is only the method of choice to generate a reliable 3D model of a protein from its amino acid sequence as notably shown in several meetings of the bi-annual critical assessment of techniques for protein structure prediction (CASP) [6]. Homology modeling is used to search the conformation space by minimally disturbing those existing solutions, i.e., the experimentally solved structures. Homology modeling technique relaxes the tough requirement of force field and enormous conformation searching, because it deals with the calculation of a force field and replaces it in large part, with the counting of sequence identities[7]. The method is based on the fact that structural conformation of a protein is more highly conserved than its amino acid sequence, and that small or medium changes in sequence normally result in little variation in the 3D structure[8]. The process of homology modeling consists of the various steps depicted in fig. 1[9]. These steps may be repeated until suitable models were built. Homology modeling is helpful in molecular biology, such as hypotheses about the drug design[10], ligand binding site[11,12], substrate specificity[13,14], and function annotation[15]. It can also provide starting models for solving structures from X-ray crystallography, NMR and electron microscopy[16,17]. The conformational constancy of homology models of channels may be assessed by subsequent molecular dynamics simulations[18,19]. Homology modeling provides structural insight of protein although quality depends on sequence similarity with the template structure[20]. Quality of model is directly linked with the identity between template and target sequences, as a rule that, models built over 50% sequence similarities are accurate enough for drug discovery applications, those between 25 and 50% identities can be helpful in designing of mutagenesis experiments and those in between 10 and 25% are tentative at superlative[2123]. In the present communication, we reviewed recent advances in the homology modeling methods, and reported some applications of homology modeling to the drug discovery process.

Figure

Fig. 1: Homology modeling process

Steps In Homology Modelling

Development of homology model is a multi steps process, that can be summarized in following way (1) identification of template; (2) single or multiple sequence alignments; (3) model building for the target based on the 3D structure of the template; (4) model refinement, analysis of alignments, gap deletions and additions, and (5) model validation[24].

Template (fold) recognition and alignment

This is the initial step in which the program/server compare the sequence of unknown structure with known structure stored in PDB (fig. 2). The most popular server is BLAST (Basic Local Alignment Search Tool)[23] (http://www.ncbi.nlm.nih.gov/blast/).A search with BLAST against the database for optimal local alignments with the query, give a list of known protein structures that matches the sequence. BLAST cannot find a template when the sequence identity is well below 30%; homology hits from BLAST are not reliable. The sequence alignment is more sensitive in detecting evolutionary relationships among proteins and genes[2527]. The resulting profile– sequence alignment properly align approximately 42-47% of residues in the 0-40% sequence identity range, this number is approximately double than that of the pair wise sequence methods[28,29]. Alignment errors are the main cause of deviations in comparative modeling even when the correct template is chosen. In recent years, significant progress has been made in the development of sensitive alignment methods based on iterative searches, e.g. PSI-BLAST[30], Hidden Markov Models (HMM), e.g. SAM[31],HMMER[32] or profileprofile alignment such as FFAS03[33], profilescan[34] and HHsearch. Multiple alignments are typically heuristic[35] well known as progressive alignment. Progressive alignments are simple to perform and allow large alignments of distantly related sequences to be constructed. This is implemented in the most widely used programs (ClustalW[36] and ClustalX[37]). Alignment of divergent protein sequences can be performed with high accuracy using ClustalW[36] program. ClustalW includes many features like assigning individual weights to each sequence in a partial alignment and amino acid substitution matrices are varied at different alignment stages according to the divergence of the sequences to be aligned. Specific importance is given to residue-specific gap penalties in hydrophilic regions which encourage new gaps in potential loop regions. HMMs[31,32] are a class of probabilistic models that are generally applicable to time series or linear sequence. Profile HMM are very effective in detecting conserved patterns in multiple sequences. The SATCHMO algorithm in the LOBSTER package simultaneously constructs a similarity tree and compares multiple sequence alignments of each internal node of the tree using HMMs. A new HMM, SAM-T98 ID known for finding remote homologs of protein sequences. The method begins with a single target sequence and iteratively builds a HMM from the sequence and homologs found using the HMM for database search. This is also used in construction of model libraries automatically from sequences. The LAMA[38] program aligns two multiple sequence alignments, first by transforming them into profiles and then comparing these two with each other by the Pearson correlation coefficient. The COMPASS[39] program was developed to locally align two multiple sequence with assessment of statistical significance, which compare two profiles by constructing a matrix of scores for matching every position in one profile to each position in the other profile, followed by either local or global dynamic programming to calculate the optimal alignment. T-Coffee uses progressive alignment as optimization technique[40]. T-Coffee can merge heterogeneous data in alignments. 3D Coffee incorporates a link to the FUGUE[41] threading package, which carries out sequence alignment using local structural information. Probabilistic-based program PROBCONS uses BAliBASE[42], which is a most accurate method available for multiple alignments. In simple words PROBCONS is like T-Coffee, but it uses probabilities instead of the heuristic algorithms. HOMSTRAD is exclusively based on sequences with known 3D structures and PDB files. Katoh et al.[43] extended the HOMSTRAD by incorporating a large number of close homologues, as found by the BLAST search, which tend to increase the accuracy of the alignment[44]. Sadreyev and Grishin[39] reported that the accuracy of profile alignments can be increased by including confident homologues with the help of COMPASS program. Further knowledge on different programs and server for sequence alignment can be gained by the surfing the URL’s provided in the Table 1.

Program Internet address
Expresso http://www.tcoffee.org/
PROMALS3D http://prodata.swmed.edu/promals3d/
3D-Coffee http://igs-server.cnrs-mrs.fr/Tcoffee/tcoffee_cgi/
  index.cgi
MUSCLE http://www.drive5.com/muscle/
PROBCONS http://probcons.stanford.edu/
PRALINE http://ibivu.cs.vu.nl/programs/pralinewww/
VAST, Cn3D http://www.ncbi.nlm.nih.gov/Structure
ClustalW http://www.ebi.ac.uk/clustalw/
SAM http://www.cse.ucsc.edu/research/compbio/sam.
  html
GENEWISE http://www.sanger.ac.uk/Software/Wise2/
MAFFT http://align.bmr.kyushu-u.ac.jp/mafft/online/
  server/
T-Coffee http://www.tcoffee.org/
PROMALS http://prodata.swmed.edu/promals/
SPEM http://sparks.informatics.iupui.edu/Softwares
  -Services_files/spem.htm
PROBE ftp://ncbi.nlm.nih.gov/pub/neuwald/probe1.0/
BLOCKS http://www.blocks.fhcrc.org/
PSI-BLAST http://www.ncbi.nlm.nih.gov/BLAST/newblast.html

Table 1: Sequence alignment programs and Their web server sites

Figure

Fig. 2: Multiple sequence alignment of ß-Arrestin family member (query is experimentally derived sequence taken from UNIPROT (ID: P32121) aligned with sequences of PDB entry codes 3P2D and 1G4M. Identical residues, conserved residues are indicated in the form of secondary structure using Discovery Studio Visualiser 2.5)

Model building

After the target–template alignment, next step in the homology modeling is the model building. A variety of methods can be used to build a protein model for the target. Generally rigid-body assembly[4547], segment matching[48], spatial restraint[49], and artificial evolution[50] are used for model building. Rigidbody assembly model building relies on the natural dissection of the protein structure into conserved core regions, variable loops that connect them and side chains that decorate the backbone. Model accuracy is based on the template selection and alignment accuracy. Accordingly, significant modeling method allows a degree of flexibility and automation, making it easier and faster to obtain good models. Segment matching based on the construction of model by using a subset of atomic positions from template structures as guiding positions, and by identifying and assembling short. All-atom segments that match the guiding positions can be obtained either by scanning all the known protein structures. In addition to that it includes those protein structures that are not related to the sequence being modeled[51], or by a conformational search restrained by an energy function[52,53]. Modeling by satisfaction of spatial restraints based on the generation of many constraints or restraints on the structure of target sequence, using its alignment to related protein structures as a guide. Generation of restraints is based upon the assumption the corresponding distances between aligned residues in the template and the target structures are similar.

Model refinement

Model refinement is a very important task that requires efficient sampling for conformational space and a means to accurately identify nearnative structures[54]. Homology model building process evolves through a series of amino acid residue substitutions, insertions and deletions. Model refinement is based upon tuning alignment, modeling loops and side chains. The model refinement process will usually begin with an energy minimization step using one of the molecular mechanics force fields[55,56] and for further refinement, techniques such as molecular dynamics, Monte Carlo and genetic algorithm-based sampling can be applied[57,58]. Monte Carlo sampling focused on those regions which are likely to contain errors, while allowing the whole structure to relax in a physically realistic all-atom force field, can significantly improve the accuracy of models in terms of both the backbone conformations and the placement of core side chains. The accuracy of alignment by modeling strongly depends on the degree of sequence similarity. Misalignment of the models some time results into the errors which may be hard to remove at the later stages of refinement[59].

Loop modeling

Homologous proteins have gaps or insertions in sequences, referred to as loops whose structures are not conserved during evolution. Loops are considered as the most variable regions of a protein where insertion and deletion often occur. Loops often determine the functional specificity of a protein structure. Loops contribute to active and binding sites. The accuracy of loop modeling is a major factor in determining the usefulness of homology models for studying proteinligand interactions[60]. Loop structures are more difficult to predict than the structure of the geometrically highly regular strands and helices because loops exhibit greater structural variability than strands and helices. Length of a loop region is generally much shorter than that of the whole protein chain. Modeling a loop region possess challenges, which are not likely to be present in the global protein structure. Modeled loop structure has to be geometrically consistent with the rest of the protein structure[61].

Loop prediction methods

Loop prediction methods can be evaluated in determining their utilities for: (1) backbone construction; (2) what range of lengths are possible; (3) how widely is the conformational space searched; (4) how side chains are added; (5) how the conformations scored (i.e., the potential energy function) and (6) how much has the method been tested. Most of the loop construction methods were tested only on native structures from which the loop to be built[62,63]. But in reality homology modeling is more complicated process requiring several choices to be made in building the complete structure. The available programs for loop structure prediction along with their web addresses are given in Table 2.

Loop prediction Internet address
methods
BRAGI http://bragi.gbf.de/index.html
BTPRED http://www.biochem.ucl.ac.uk/bsm/btpred/
RAMP http://www.ram.org/computing/ramp/
  ramp.html
CONGEN http://www.congenomics.com/congen/doc/
  index.html
Drawbridge http://www.cmpharm.ucsf.edu/cohen/
Swiss-PDB Viewer http://spdbv.vital-it.ch/

Table 2: Loop Modeling Program

Database methods

Database methods of loop structure prediction measure the orientation and separation of the backbone segments, flanking the region to be modeled, and then search the PDB for segments of the same length that span a region of similar size and orientation. In current years, as the size of the PDB has increased, database methods have continued to attract attention. Database methods are suitable for the loops of up to 8 residues[64].

Construction methods

The main alternative to database methods is construction of loops by random or exhaustive search mechanisms. Moult and James[65] performed a systematic search to predict loop conformations up to 6 residues long. They found various useful concepts in loop modeling by construction: (1) the use of a limited number of Φ, ψ pairs for construction; (2) construction from each end of the loop simultaneously; (3) discarding conformations of partial loops that span the remaining distance with those residues left to be modeled; (4) using side-chain clashes to reject partial loop conformations and (5) the use of electrostatic and hydrophobic free energy terms in evaluating predicted loops[66].

Scaling-relaxation method

In scaling-relaxation method a full segment is sampled and its end-to-end distance is measured. If this distance is longer than the segment needs, then the segment is scaled in size so that it fits the end-toend distance of the protein anchors, which result in very short bond distances, and unphysical connections to the anchors. From there, energy minimization is performed on the loop, slowly relaxing the scaling constant, until the loop is scaled back to full size[67,68].

Molecular mechanics/molecular dynamics

Other loop prediction methods build chains by sampling Ramachandran conformations randomly, keeping partial segments as long as they can complete the loop with the remaining residues to be built[69]. These methods are capable of building longer loops since they spend less time in unlikely conformations searched in the grid method. These methods are based on Monte Carlo or molecular dynamics simulations with simulated annealing to generate many conformations, which can then be energy minimized and tested with some energy function to choose the lowest energy conformation for prediction[68,70].

Side-chain modeling

Side-chain modeling is an important step in predicting protein structure by homology. Side-chain prediction usually involve placing side chains onto fixed backbone coordinates either obtained from a parent structure or generated from ab initio modeling simulations or a combination of these two. Protein side chains tend to exist in a limited number of low energy conformation called rotamers. In side-chain prediction methods (Table 3), rotamers are selected based on the preferred protein sequence and the given backbone coordinates, by using a defined energy function and search strategy. The side-chain quality can be analyzed by root mean square deviation (RMSD) for all atoms or by detecting the fraction of correct rotamers found[71?73].

Side-chain prediction Internet address
methods
RAMP http://www.ram.org/computing/ramp/
  ramp.html
SCWRL http://www.fccc.edu/research/labs/
  dunbrack/scwrl
Segmod/CARA http://www.bioinformatics.ucla.
  edu/~genemine
SMD http://condor.urbb.jussieu.fr/Smd.html

Table 3: Side Chain Modeling Program

Model validation

Each step in homology modeling is reliant on the former processes. Therefore, errors may be accidentally introduced and propagated, thus the model validation and assessment of protein is necessary for interpreting them (Table 4). The protein model can be evaluated as a whole as well as in individual regions[74]. Initially, fold of a model can be assessed by a high sequence similarity with the template. One basic necessity for a constructed model is to have good stereochemistry[75]. The most important factor in the assessment of constructed models is scoring function. The programs evaluate the location of each residue in a model with respect to the expected environment as found in the high-resolution X-ray structure[76]. Techniques used to determine misthreading in X-ray structures can be used to determine alignment errors in homology models. Errors in the model are very much common and most attention is needed towards refinement and validation. Errors in model are usually estimated by (1) superposition of model onto native structure with the structure alignment program Structal[77] and calculation of RMSD of Ca atoms[78]; (2) generation of Z-score, a measure of statistical significance between matched structures for the model, using the structure alignment program CE, scores four indicate good structural similarity and (3) development of a scoring function that is capable of discriminating good and bad models. Statistical effective energy functions[79] are based on the observed properties of amino acids in known structures. A variety of statistical criteria derived for various properties such as distributions of polar and apolar residues inside or outside of protein, thus detecting the misfolded models[80]. Solvation potentials can detect local errors and complete misfolds[81]; packing rules have been implemented for structure evaluation[82]. A model is said to be valid only when a few distortions in atomic contacts are present. The Ramachandran plot is probably the most powerful determinant of the quality of protein[83,84], when Ramachandran plot quality of the model is comparatively worse than that of the template, then it is likely that error took place in backbone modeling. WHAT_CHECK determines Asn, His or Gln side chains need to be rotated by 180° about their C2, C2 or C3 angle, respectively. Side chain torsion angles are essential for hydrogen bonding, sometimes altered during the modeling process. Conformational free energy distinguishes the native structure of a protein from an incorrectly folded decoy. A distinct advantage of such physically derived functions is that they are based on welldefined physical interactions, thus making it easier to learn and to gain insight from their performance. In addition, ab-initio methods showed success in recent CASP. One of the major drawbacks of physical chemical description of the folding free energy of a protein is that the treatment of solvation required usually comes at a significant computational expense. Fast solvation models such as the generalized born and a variety of simplified scoring schemes[85] may prove to be extremely useful in this regard. A number of freely available programs can be used to verify homology models, among them WHAT_CHECK (Table 4) solves typically crystallographic problems[86]. The validation programs are generally of two types: (1) first category (e.g. PROCHECK and WHATIF) checks for proper protein stereochemistry, such as symmetry checks, geometry checks (chirality, bond lengths, bond angles, torsion angles models[80]. Solvation) and structural packing quality and (2) the second category (e.g.VERIFY3D and PROSAII) checks the fitness of sequence to structure and assigns a score for each residue fitting its current environment. GRASP2 is new model assessment software developed by Honig[87]. For example, gaps and insertions can be mapped to the structures to verify that they make sense geometrically. It is suggested that, manual inspection should be combined with existing programs to further identify problems in the model.

Program Internet address
PROCHECK http://www.biochem.ucl.ac.uk/~roman/procheck/ procheck.html
WHATCHECK http://www.sander.embl-heidelberg.de/whatcheck/
ProsaII http://www.came.sbg.ac
VERIFY3D http://www.doe-mbi.ucla.edu/Services/Verify_3D/
 ERRAT http://www.doe-mbi.ucla.edu/Services/Errat.html
ANOLEA http://www.fundp.ac.be/pub/ANOLEA.html
Probe http://kinemage.biochem.duke.edu/software/ probe.php

Table 4: Model assessment and validation Program

Software for Homology Modeling

Several programs and servers are available for homology modeling that are planned to build a complete model from query sequences. MODELLER developed by Andrej Sali and colleagues[88,89], SwissModel[90,91], RAMP, PrISM[92], COMPOSER[64,93] CONGEN+2[94,95] and DISGEO/Co-nsensus[96,97] are some of the examples. Homology modeling techniques are described in a number of available programs, both in the commercial and public area (Table 5). A comparative study of available modeling programs and servers (Table 6) for high-accuracy homology modeling has been captured in some excellent publications[98,99]. The authors tried to evaluate several characteristic of the homology modeling programs, including (1) the reliability; (2) the speed by which the programs build models and (3) the similarity of the structure.

Programs Name WWW address Availability
SWISS-MODEL* http://swissmodel.expasy.org/ Academically free

MODELLER** http://salilab.org/modeller/ Academically free

ExPASy * http://www.expasy.ch/tools/ Academically free

BLAST* http://blast.ncbi.nlm.nih.gov/Blast.cgi Academically free

SCHRODINGER** http://www.schrodinger.com Commercial

WHATIF* http://swift.cmbi.kun.nl/whatif/ Academically free

SYBYL** http://www.tripos.com Commercial
SNPWEB* http://modbase.compbio.ucsf.edu/LS-SNP/ Academically free

ICM http://www.molsoft.com/homology.html Academically free

SEA * http://bioinformatics.burnham.org/sea/ Academically free

SCWRL* http://www1.jcsg.org/prod/scripts/scwrl/serve.cgi Academically free

EVA* http://rostlab.org/cms/index.php?id=94 Academically free

VERIFY3D* http://nihserver.mbi.ucla.edu/Verify_3D/ Academically free

MOE** http://www.chemcomp.com/software.htm Commercial

GOLD** http://www.ccdc.cam.ac.uk/products/life_sciences/gold/ Commercial
PROCHECK* http://www.ebi.ac.uk/thornton-srv/software/PROCHECK/ Academically free
*Server, **Program

Table 5: Server and programs useful in Homology modeling

Modeling program Potential energy Search method Description
MODELLER CHARMM Spatial restraints Modeling by satisfying spatial restraints
SwissModel GROMOS Rigid-body assembly Web server using rigid-body assembly with loop modeling
COMPOSER Rigid-body assembly Use of multiple template structures for building homology model
3D-JIGSAW Mean-field minimization methods Rigid-body assembly Web server using rigid-body assembly with loop modeling
PrISM Rigid-body assembly Most appropriate template is used for each segment of the targetto be built
CONGEN CHARMM Rigid-body assembly Distance constraints derived from known structure and alignment.

Table 6: Comparison Of Software For Homology Modeling

Modeller

MODELLER uses the query structures to construct constraints on atomic distances, dihedral angles, and so forth, these are then combined with statistical distributions derived from many homologous structure pairs in the PDB. MODELLER combines the sequences and structures into a complete alignment which can then be examined using molecular graphics programs and edited manually[88,89].

SwissModel

SwissModel is accessible via a web server that accept the sequence to be modeled, and then delivers the model by an electronic mail[100]. In contrast to Modeller, SwissModel follows the standard protocol of homologue identification, sequence alignment, determining the core backbone and modeling loops and side chains. SwissModel will search a sequence database of proteins in the PDB with BLAST, and will attempt to build a model for any PDB hits[90,91].

PrISM

PrISM performs homology modeling using alignment to builds a composite template by selecting each secondary structure from the most appropriate template. Ab initio methods are used for loop modeling and side-chain dihedrals are taken either from the template or predicted structure based on main chain torsion angles and a neural network algorithm[92].

COMPOSER

COMPOSER uses multiple template structures for building homology models. If a target sequence is related to more than one template (of different sequence) then all templates are used to provide an average framework for building the structure[64,93].

CONCEN

CONCEN develops distance restraints from the template structure and the sequence alignment of the target and template for atoms. These atoms include all backbone atoms and side-chain atoms of the same chemical type and hybridization state. No homologous atoms are defined in the loop regions[94,95].

Critical assessment of techniques for protein structure prediction (CASP):

CASP experiments are biannual and their main aim is to set benchmarking standards to the protein structure prediction methods followed by various online servers and software. They monitor the state of the art in modeling protein structure from the sequence. The main objective behind these experiments is to ensure overall quality of the models, accuracy of prediction and evaluating the parameters provided by the various tools. The independent assessors evaluate predictions using a battery of numerical criteria[101]. There are several conclusions drawn from the CASP such as, the comparative modeling remained most accurate technique for protein structure modeling when compared with others. Although majority of predictions were again closer to the template than to the real structurethere has been improvement in some cases. However, accurate modeling by using a single template is not possible and model refinement has always been a challenge till date. Drastic changes are being done to the algorithm to meet the standards by various tools. Eighteen successful refinements of model coordinates to a value closer to the experimental structure were observed in CASP 7. Model refinement has been identified as an area in which further developments are required to be done[102?105]. Readily available models for a given sequence, such as those generated by automated servers often form the basis for the input to model refinement methods. Previous attempts have included molecular dynamics[106], Monte Carlo[107] and knowledgebased techniques[108]. However automated prediction servers have found to improve their algorithms and models predicted were closer to the experimentally determined. The function prediction category (FN) was introduced in the 6th CASP (Table 7), where predictions for gene ontology molecular function terms, enzyme commission numbers and ligand-binding site residues were evaluated. These services, EVA[109], LiveBench[110] and CASP are very useful for the protein structure prediction community, giving clear observations of the development and the need for further progression within the field. Results of several CASP experiments and evaluations are made publicly available through the prediction centre website (http://predictioncenter. org). The latest advances in structure prediction and assessment of model quality are to be evaluated by CASP 10th in the year 2012.,

Rank CASP ID Name
1 FN096 ZHANG
2 FN339 I-TASSER_FUNCTION
3 FN315 FIRESTAR
4 FN242 SEOK
5 FN035 CNIO-FIRESTAR
6 FN110 STERNBERG
7 FN104 JONES-UCL
8 FN094 MCGUFFIN
9 FN113 FAMSSEC
10 FN114 LEE

Table 7: Casps results in the function Prediction category (fn)

Applications of Homology Modeling

Homology modeling is widely used in structure based drug design process. The importance of homology modeling is increasing as the number of available crystal structures increases. There are several other common applications of homology models: (1) studying the effect of mutations[111]; (2) identifying active and binding sites on protein (useful for ligand design) [112]; (3) searching for ligands of a given binding site (database mining)[113]; (4) designing novel ligands of a given binding site; (5) modeling substrate specificity[114]; (6) predicting antigenic epitopes[115]; (7) protein?protein docking simulations[116]; (8) molecular replacement in X-ray structure refinement[117]; (9) rationalizing known experimental observations[118] and (10) planning new computational experiments with the provided models. Typical applications of a homology model in drug discovery require a very high accuracy of the local side chain positions in the binding site. A very large number of homology models have been built over the years. Targets have included antibodies[119] and many proteins involved in human biology and medicine[120,121].

Case study of G-protein coupled receptors (GPCRs):

GPCRs constitute the largest family of signalling receptors in the cell and therefore being target for nearly half of all drug discovery programs. In the year 2000 only a single crystal structure was available, bovine rhodopsin (bRho) (PDB code 1f88, 1l9h), before which bacterio-rhodopsin was used for modeling. Recently, the appearance of crystal structures of four new GPCRs (Opsin, 3cap; ß2 adrenergic (ß2-AR), 2rh1; turkey b1 adrenergic (ß1- AR), 2vt4; human A2A adenosine receptor, 3eml) brings a broader template diversity for in silico modeling. The newly crystallized ß2-AR has been already investigated as an alternative template to model other Class-A GPCRs for drug discovery applications[122]. Analyzing the bovine rhodopsin structure with the human ß2-adrenergic receptor (2rh1) gives basis for understanding some facts and drawbacks of the modeling techniques used earlier for GPCR?s[123]. Arrangement of the seven trans-membrane helix segments is generally correctly represented, and significant differences was observed in the relative orientation and shifts of the helices with regard to the centre of the receptor. Most deviations are observed for helices III, V and the extracellular loop ECL2, which connects helices IV and V, while ECL2 is forming a ß-sheet structure in rhodopsin. ß2-adrenergic receptor contains an unexpected additional a-helical segment and a second disulfide bridge that might stabilize the more solvent exposed conformation. Consequently, specific interactions between the ligand molecule and side chains forming the binding pocket are only partially reproduced by a comparative model based on rhodopsin. A novel ligand-steered homology modeling method was presented recently[124], in which the information about known ligands is explicitly used to shape and optimize the binding site through a docking-based stochastic global energy minimization procedure[125?128]. This method is useful to reduce the uncertainty in modeling the binding site, as both the ligand and receptor are held flexible during modeling. A combination of homology modeling and molecular dynamics studies on known inhibitors crystallized with other homologous proteins was used to shape and optimize the binding site of the ribosomal S6 kinase 2 (RSK2), target for human breast and prostate cancer. Subsequent docking reported two low micromolar inhibitors[129]. Homology models have proved to be an important source to rationalize SAR data and predict binding modes of compounds like cannabinoid receptor-2[130,131], human adenosine A2A receptor[132] and alpha-1-adrenoreceptors[133].

Homology model-based ligand design

The Applications of homology modelling in ligand designing is given in Table 8. Watts et al.[134] generated two homology models of the gastric H+/K+-ATPase in the E1 and E2 conformations of its catalytic cycle based on templates provided by its related P-type ATPase (Ca2+-ATPase). Generated models were based on the CLUSTALW alignment, G-factor ranks values above -0.5 as positive candidates for homology models. In this study, the values were found to be exceeding -0.5 and ranged from -0.34 to -0.05. Correlation between the results of ligand docking and existing mutagenesis information for the protein showed that the models are realistic and could reveal an insight into the binding mechanism for a class of site-specific reversible inhibitors of the gastric H+/K+-ATPase. A 3D model of the AT1 receptor was constructed[135] using X-ray structure of bovine rhodopsin as template. The site-directed mutagenesis data was also taken into account. Docking based alignment was used for the development of a 3D-QSAR model for several non-peptide antagonists. The results of this study confirmed the binding hypothesis and reliability of the model. Cavasotto et al.[136] developed a ligand-steered homology modeling approach followed by docking-based virtual screening to model melanin-concentrating hormone receptor 1 (MCH-R1). MCH-R1 is a GPCR and a target for obesity. Ligand-steered homology modeling method was applied to shape and optimize the binding site, which reduced the uncertainty in its structural characterization by homology modeling. The authors reported that the absence of solid experimental evidence has led them to use smallscale virtual screening for model validation. They evaluated the accuracy of the models by estimating the ability to discriminate binders and nonbinders in a virtual screening of known MCH-R1 antagonists seeded within a GPCR class A ligand library. Wiest et al.[137] constructed 3D models of class I histone deacetylases, HDAC1, HDAC2, HDAC3, and HDAC8 for understanding of differences between the isoforms of class-I HDAC. A series of HDAC inhibitors were docked to understand the similarities and differences between the binding modes. The results of the study helped in design of novel HDAC inhibitors. 3D structure of Fyn kinase was modeled[138] using the Sybyl-Composer. Rosmarinic acid was evaluated as a new Fyn kinase inhibitor using immunochemical and in silico methods. In the process to identify possible active site of homology model for docking of the ligands, PDB data was searched for solved crystal structures of tyrosine kinases in complex with ligands. The crystal structure of Lck complexed with staurosporine (1QPJ) was spatially aligned with model of the Fyn. Active sites of both structures were carefully analyzed, and the most important differences in the residue positions were identified. The study reported that the rosmarinic acid binds to the second ?non-ATP? binding site of the Fyn tyrosine kinase.Yang et al.[139] constructed homology models of the carboxyl-transferase domain of acetyl-coenzyme A carboxylase from sensitive and resistant foxtail and used these models as templates to study the molecular mechanism and stereochemistry-activity relationships of aryloxyphenoxypropionates (APPs). Further docking analysis using the Insight II program indicated that the binding model of highly active compounds was similar to that in the crystal structure of enzyme-ligand complexes. A 3D protein model of the human histamine H4R has been constructed by Leurs et al.[140] using rhodopsin as template. The derived computational model was able to explain the experimental data obtained for several mutant receptors at the fundamental atomic level. All simulations were performed using Amber99 force field in MOE 2006.08. Reichert et al.[141] reported homology models for both human D2L and D3 receptors in complex with haloperidol using MODELLER 9.2. Further structure and ligand-based approach was explored for a class of D2-like dopamine receptor ligands. 3D-QSAR analyses were performed to explore the intermolecular interactions of a large library of ligands with dopamine D2/ D3 receptors. Chen et al.[142] employed molecular dynamics simulation techniques to identify the predicted D2 receptor structure. Homology models of the protein were developed on the basis of crystal structures of four available receptor crystals. Clustal X 2.09 program was used for sequence alignment and MODELLER program was used to model D2 receptor. Docking studies revealed the possible binding mode and five other residues (Asp72, Val73, Cys76, Leu183 and Phe187) which were responsible for the selectivity of the tetralindiol derivatives. The result of this study revealed that constructed novel models can be used to design new protease antagonists.

Protein structure Program/Server Reference
Gastric H+/K+-ATPase MODELLER, PROCHECK, PROFIT, AUTODOCK3.0,CLUSTALW, ProsaII3.0 [134]
AT1 receptor MODELLER, AUTODOCK, PROCHECK, MACROMODEL [135]
Melanin-concentrating hormone receptor 1 (MCH-R1) MODELLER [136]
Histone deacetylases (HDACs) MODELER 7, WHAT IF, AutoDock 3.0, BLAST [137]
Fyn tyrosine kinase SYBYL, BLASTP, GOLD, FlexX [138]
Acetyl CoA SWISS-MODEL, CLUSTALW, [139]
carboxylase PROCHECK, Sybyl 7.0
Human histamine H4 receptor (H4R) MOE [140]
Human dopamine (D2L and D3) receptors MODELLER 9.2, SYBYL7.2, PROCHECK [141]
Dopamine D2 receptor MODELER, SYBYL Clustal X 2.09, BLAST, [142]

Table 8: Applications Of Homology Modeling Relevant To Ligand Design

Structure-based homology modeling

The structure based homology modelling studied are given in Table 9. Nowak et al.[143] constructed rhodopsin-based homology model of 5-HT1A serotonin receptor. The crystal structure of bovine rhodopsin was used as a template structure. Modeller was used to produce 400 models and a cyclohexylarylpiperazine derivative was docked to all the 400 receptor models using FlexX. Ligand binding mode in the 5-HT1A receptor was analyzed based on top-scored ligand-receptor complexes. The main objectives of this study was to validate the model with a decreased conformational flexibility, which encoded the information on a shape of binding site and the spatial arrangement of specific interaction points within the binding pocket. The anaplastic lymphoma kinase (ALK) is a receptor tyrosine kinase normally expressed in neural tissues during embryogenesis is a valid target for anticancer therapy. In the absence of a resolved crystal structure of ALK, Passerini and colleagues[144] generated homology models of the ALK kinase domain in different conformational states. The authors observed that mutation of the leucine residue in ALK to a smaller threonine residue, which was found sufficient to allow binding of the inhibitors inside the ATP pocket and consequently, inhibition of mutated ALK. Evers et al.[145] modeled alpha1A receptor based on the X-ray structure of bovine rhodopsin (template). The authors applied a modified version of the MOBILE approach (modelling binding sites including ligand information explicitly), which modeled protein by homology including information about bound ligands as restraints, thus resulting in more relevant geometries of protein binding sites. Virtual screening study identified putative alpha1A receptor antagonists. The authors mentioned that among the 80 top-scored hits, 37 revealed affinity below 10 µM, with 24 compounds binding in the submicromolar range. Chemokine receptors (CCRs) are the members of the GPCRs, identified as potential target systems for preventing virus-cell fusion. The authors[146] modeled a 3D structure of the human CCR5 from the bovine rhodopsin by incorporating extensive molecular dynamics simulations (MD), flexible docking of a synthetic antagonist and soft protein-protein docking with the large (70 KD) natural agonists using some novel docking protocol. The results of this combined modeling, dynamics and docking study provides new structural insights into CCR5/chemokine interactions, which may be useful in the rational design of HIV-1 entry blockers. Tuccinardi et al.[147] developed a homology model of carbonic anhydrase (CA) IX using the X-ray structure of murine CA XIV as a template. CA IX constitutes an interesting target for cancer therapy. The authors docked one twenty four CA IX inhibitors, and the best poses were used for developing a receptorbased 3D-QSAR model. The results of the study suggested structural peculiarities which can be useful for the design of new CA IX active and CA IX/ CA II selective ligands. Avery et al. [148] generated highly refined homology models of Leishmania donovani farnesyl pyrophosphate synthase (LdFPPS) and Leishmania major FPPS (LmFPPS) enzyme using Trypanosoma cruzi FPPS (TcFPPS) as a reference structural homologue. The authors suggested that highly refined model along with the validated docking and scoring algorithms could be utilized to identify hits with novel scaffolds as antileishmanial agents. Pietra et al.[149] constructed homology models of acidsensing cation-permeable, ligand-gated ion channel (hASIC1) using the crystal structure of the cASIC1 channel as a template and the known sequence of hASIC1a. ASIC channels are under intense scrutiny for their ability in sensing proton gradients. Psalmotoxin 1 (PcTx1) - a peptide isolated from the venom of the aggressive Trinidad chevron tarantula (Psalmopoeus cambridge) is a inhibitor of ASIC. The results of the study showed the way to in silico search for improved peptides, for blocking ASIC1a channels. Yuriev et al.[150] constructed homology models of dopamine (D2, D3 and D4), serotonin (5-HT1B, 5-HT2A, 5-HT2B and 5-HT2C), histamine (H1), and muscarinic (M1) receptors using ß2-adrenergic receptor. The authors performed induced fit docking for binding site optimization and virtual screening of known ligands and decoys. The study addressed the required modeling of extracellular loop 2, which is implicated in ligand binding. Feng et al.[151] generated homology models of cytochrome P450 sterol 14R-demethylases (CYP51s) from Penicillium digitatum (PD-CYP51). The preceding 3D structure of PD-CYP51 was further subjected to a molecular dynamic (MD) study to reduce steric clashes and obtain converged 3D modeling structure of PD-CYP51. After active site generation docking-based virtual screening was performed using FlexX/GOLD. The seven new hit compounds with comparable inhibitory activities were identified. Zhang et al.[152] constructed homology model of human D3 receptor using the X-ray crystal structure of the human ß2AD receptor (PDB entry: 2RH1, resolution 2.4 Å) as the template structure. The authors performed combined computational study to investigate the agonist binding to the D3 receptor, which is important for the design of potent D3 receptor agonists. Marabotti et al.[153] constructed homology models of human galactose-1-phosphate uridylyltransferase (GALT). The genetic disorder called ?classical galactosemia? or ?galactosemia I? is associated with the impairment of GALT. Mutation is associated with genetic galactosemia. The authors analyzed the impact of this mutation both on enzyme-substrate interactions as well as on inter-chain interactions. It was concluded from the study that constructed model will be useful for characterization of all galactosemialinked mutations at a molecular level. Inhibition of serum carnosinase may be a useful therapeutic approach in the treatment of diabetic nephropathy. Vistoli et al.[154] constructed homology models of human serum carnosinase on the basis of ß-alanine synthetase structure. Homology model was validated by docking a few histidine-containing dipeptides, later on, molecular dynamics (MD) simulations were used to examine the effects of citrate ions on the activity of serum carnosinase.

Protein Program/Server Reference
Serotonin 5-HT1A Receptor MODELLER 7v7, SYBYL 7.0, FlexX [143]
 Anaplastic lymphoma kinase (ALK) MODELLER 6v2, FlexX [144]
Alpha1A adrenergic receptor MOE, MOBILE, GOLD2.0, Sybyl 6.92 [145]
 Human CCR5 chemokine receptor MODELLEER 6.2, NMRCLUST, GridHex38  146
Carbonic Anhydrase IX MODELLER 9v1, PROCHECK, GOLD [147]
LeishmanialFarnesyl Pyrophosphate Synthases MODELLER 7.0, SWISS-PROT, BLAST, Sybyl 6.9, InsightII [148]
 hASIC1a ion channel MODELLER 9v4, DOT 2.0, SHAKE [149]
Aminergic GPCRs Dopamine (D2, D3, and D4), serotonin (5-HT1B, 5-HT2A,5-HT2B, and 5-HT2C), histamine (H1), and muscarinic (M1) receptors MODELLER, Sybyl, Prime, ICM [150]
 Cytochrome P450 sterol 14a-demethylase AMBER 8.0, CPHmodels2.0, FlexX/GOLD, PROCHECK, SYBYL 7.0, PMF, DOCK [151]
Dopamine (D3) receptor Modeller 9v2, GOLD [152]
 Human galactose-1-phosphateuridylyltransferase MODELLER, PROCHECK [153]
Human serum carnosinase FlexX, STRIDE [154]

Table 9: Applications Of Structure-Based Homology Modeling

Loop structure prediction

The homology modelling is very good tool for prediction of loop structures, the exaples are given in Table 10. Loops frequently resolved the functional specificity of a protein environment, thus contribute to active and binding sites. Zhang et al.[155] developed homology models of the lysophosphatidic acid (LPA4) receptor based on the X-ray crystal structures of photoactivated bovine rhodopsin (PDB code 1U19). GOLD, was employed to dock LPA molecule into the homology models of the receptors. It was observed that three non-conserved amino acid residues engaged in hydrogen bonding interactions with the polar head group of the LPA molecule. These hydrogen bonding patterns were found to contribute significantly to the recognition of LPA within the LPA4 receptor. Turjanski et al.[156] modeled the structure of Trypanosoma cruzi fanesyl pyrophosphate synthase (TcFPPS) based on the structure of the avian FPPS which share 36% identity and 50% similarity with the sequence of TcFPPS. The authors constructed the model using Swiss PDBViewer version 3.7. The authors modeled the interaction of TcFPPS with isopentenyl pyrophosphate and dimethylallyl pyrophosphate. Based on the study, authors have proposed specific role for the third Mg2+ in closing of the protein active site based on molecular dynamics simulations (MD). Scapozza et al.[157] constructed homology models of Varicella Zoster virus thymidine kinase (VZV TK) based on herpes simplex virus type 1 thymidine kinase (HSV-1 TK) structure as template. Acyclovir and ganciclovir were docked in the constructed model to investigate the predictivity of these model as well as the characteristics of the binding with other substrates. It was found that there are slight differences in the way VZV TK binds the substrates in respect with HSV-1 TK. Missing loops in the VZV TK was modeled using the loop search routine of SYBYL 6.8. The study suggested that differences could be exploited for future ligand design in order to obtain more selective drugs. Li et al.[158] built homology models for a glycogen synthase kinase (GSK3)/SHAGGY-like kinase based on the known crystal structure of glycogen synthase kinase-3ß (Gsk3 ß PDB code:1I09). Initial module of GSK-3ß was obtained with the help of FASTA program. Binding pocket of GSK3/SHAGGY-like kinase was determined by binding site search module. Several variable regions (loops) were constructed using loop searching algorithm. Optimization of structure was done by INSIGHT-II and PROFILE-3D. The authors[159] constructed homology models of hemoglobin-binding protein HgbA from Actinobacillus pleuropneumoniae using BtuB, FepA, FhuA and FecA of Escherichia coli as template structure. Using HMM the authors assigned ß strands to regions of predicted HgbA amino acid sequence, culminating in a structure-based multiple sequence alignment to BtuB, FepA, FhuA, and FecA. 3D model generated from this alignment provides an overall topology of HgbA and identifies extracellular loop regions.

Protein Program/Servers Reference
Lysophosphatidic acid LPA4 receptor SYBYL v7.3, GOLD 3.1, SCWRL 3.0 [155]
Farnesyl pyrophosphate synthase PSI-BLAST, Swiss- PDBViewer v3.7, WHATCHECK, AMBER 7.0 [156]
Varicella zoster virus thymidine kinase (VZV TK) SYBYL 6.8, AUTODOCK 3.0, SHAKE, AMBER, PROCHECK [157]
Glycogen synthase kinase (GSK3/SHAGGY) FASTA, INSIGHT-II, PROFILE-3D [158]
Hemoglobin-binding protein HgbA PROCHECK, WHAT IF, Modeller [159]

Table 10: Applications Of Homology Modeling Relevant To Loop Structure Prediction

Miscellaneous applications of homology modeling for protein structure prediction

Pillai et al.[160] provided a structural basis for the biological functions of human Smad5 by building a model of the DNA-binding domain of it. The authors reported similarities and differences between the human Smad family members using the constructed model. Gellert et al.[161] constructed homology models of cucumber mosaic virus (CMV) strains R, M and Trk7, tomato aspermy virus (TAV) strain P and peanut stunt virus (PSV) strain Er, using Fny-CMV CP subunit B as a template. Models were analyzed by the PROCHECK program and electrostatic potential calculations were applied to all models. Guo et al.[162] developed 3D model of human phosphate mannose isomerase based on the known crystal structure of mannose-6-phosphate isomerase (PDB code: 1PMI). The homologous protein was searched by the FASTA program and 3 reference proteins were taken i.e. mannose-6-phosphate isomerase from C. albicans, B. subtilis and human. The sequence alignment was done based on identification of structurally conserved regions (SCRs). This study facilitated the understanding of the mode of action of the ligands and guided further genetic studies. Reddanna et al. [163] generated homology models of human 12R-LOX structure, based upon rabbit reticulocyte 15-Lipoxygenase 1LOX as a template. The 3D model was built using Modeller and BLAST, ClustalW for sequence alignment, AMBER 3.0 for refinement and PROCHECK was used for validation of themodel. The authors[164] built 3D structure of the chorismate synthase (CS) from S. flexneri with the cofactor FMN and using MODELLER 6 v.2. The AMBER 8.0 program and AMBER 2003 force field were used for molecular simulation. CS is a valid target for antibacterial drugs. Hirashima et al. [165] suggested homology models of octopamine receptor (OAR2) of Periplanata americana using DS Modeling 1.1 using rhodopsin as a template. BLAST and PSI-BLAST were used for alignment, and docking study was performed using LigandFit. These models can be used in scheming new leads for OAR2 receptors. Kayastha et al.[166] constructed homology models of a-amylase from germinated mung beans (Vigna radiata) using the automated Swissmodel server where two known structure of amylase AMY1 and AMY2 were chosen as a templates. The sequence identity between target and templates is over 65%. The Ramachandran Z-score for the model is -1.132. Serrano et al.[167] presented model for the 3D structure of the C-terminal 19 kDa fragment of P. vivax MSP-1, based on the known crystal structure of P. cynomolgy MSP-119. The presence of a main binding pocket was determined by CASTp and the combination of GOLD docking and scoring functions was used to observe the interaction between Akt PH (protein kinase ß pleckstrin) domain and its inhibitors. Park et al.[168] constructed homology models for yeast ß-glycosidase using BLAST, PSI BLAST and MODELLER. Furthermore, the author performed virtual screening with docking simulations to study the effects of ligand solvation in the binding free energy function which results in 13 novel a-glucosidase inhibitors. Wang et al.[170] used human cytochrome P450 2C8 (CYP2C8) as template and created human cytochrome P450 2C11 (CYP2C11) and human cytochrome P450 2C13 (CYP2C13) models. The authors demonstrated the pattern of testosterone binding with various human cytochrome P450 enzymes. Rigid structure and inducedfit docking proposed that testosterone binds in both CYP2C11 and CYP2C13. These results demonstrated the binding of substrate to CYPs. Kotra et al.[171] modeled two new epidermal growth factor receptors (EGFR) taking SYK tyrosine kinase coordinates as template. Mutation was incorporated at G695S and L834R to develop the new receptor structures. This study determined the receptor-inhibitor interactions and thus provides rational approach to design and development of potent inhibitors. Construction of homology models of dipeptide epimerase suggested novel enzymatic functions[172]. Docking of dipeptide library against the binding site of these models was performed using Glide. The dipeptide library was prepared by using Ligprep. Homology modeling of trihydroxynaphthalene reductase (3HNR) was performed with 17b-HSDcl as a template, which possesses 58% identical residues. Molecular modelling package WHATIF was used along with the CHARMM program for macromolecular simulations. The study of 3HNR explained the binding modes of the ligand with the model. Chavatte et al.[173] constructed models for both human melatoninergic (MT1 and MT2) receptors by homology modeling using the X-ray structure of bovine rhodopsin as template. Models were checked using Ramachandran plots to assess the quality of structure. No residue lies in the disallowed part of the plots and very few residues are in the less favourable regions. Thus, constructed models can be explored at an atomic level for the melatoninergic receptors. Yao et al.[174] studied the two metabolic pathway for gliclazide by building homology models of human cytochrome P450 2C9 (CYP2C9) and human cytochrome P450 2C19 (CYP2C19) enzyme. Structural optimization was performed using molecular mechanics and molecular dynamics simulations. To further check the reliability of the 3D structure of models, the automated molecular docking was performed using docking program Insight II. It was found that affinity for methylhydroxylgliclazide pathway found to be more than 6ß-hydroxylgliclazide with respect to both refined model of CYP2C19 and crystal structure of CYP2C9.

Conclusion

Structure-based drug design techniques were hampered in the past by the lack of a crystal structure for the target protein. In this instance, now a day the best option is building a homology model of the entire protein. The main aim of homology modeling is to predict a structure from its sequence with an accuracy that is similar to the results obtained experimentally. Homology modeling provides a feasible cost-effective alternative method to generate models. Homology modeling studies are fastened through the use of visualization technique, and the differential properties of the proteins can be discovered. The role and reliability of homology model building will continue to grow as the number of experimentally determined structures increases. Homology modeling is a powerful tool to suggest modeling of ligand-receptor interactions, enzymesubstrate interactions, mutagenesis experiments, SAR data, lead optimization, loop structure prediction and to identify hits. Homology modeling strongly relies on the virtual screening and successful docking results. Various examples of the successful applications of homology modeling in drug discovery are described in this review. These recent advances should help to improve our knowledge of understanding the role of homology modeling in drug discovery process.
