Synthesis and biological evaluation of delavayin-C

Corresponding Author:

Nirmala V. Shinde
Department of Pharmaceutical Chemistry, N. G. S. M. Institute of Pharmaceutical Sciences, Nanthoor, Mangalore-575 005, India
E-mail: nirmala_h2o@rediffmail.com

Abstract

The synthesis of a cyclic heptapeptide, delavayin-C, cyclo(gly-tyr-tyr-tyr-pro-val-pro) is described. The structure of this compound was established on the basis of analytical IR, 1 H NMR and FAB mass spectral data. The antibacterial and antifungal activities of this peptide are also described.

Keywords

Cyclic peptide, delavayin-C, antibacterial, antifungal, p-nitrophenylester method.

Cyclic peptides were found to exhibit various biological activities like antibacterial, antifungal, anthelmintic, insecticidal, antineoplastic, antitumor, antiinflammatory activities [1-6]. Keeping in view of the significant biological activities exhibited by various cyclic peptides, as a part of ongoing study, an attempt was made towards the synthesis of a cyclic heptapeptide, delavayin-C, cyclo(gly-tyrtyr- tyr-pro-val-pro), which was isolated from the roots of Stellaria delavayi and belongs the family Cariophyllaceae [7]. The synthesized compound was further subjected to antibacterial activity against Bacillus subtilis, Staphylococcus aureus, Escherichia coli and Psuedomonas aeruginosa and antifungal activities against Candida albicans.

The synthesized compound has shown moderate antibacterial and antifungal activity comparable with the standard drug benzyl penicillin and standard antifungal agent fluconazole, respectively. Spectral interpretation and elemental analysis was done for the synthesized compound for structural elucidation.

In order to carry out the total synthesis of cyclic peptide, cyclo(gly-tyr-tyr-tyr-pro-val-pro), it was disconnected into three dipeptide units, Boc-glytyr- OMe 1, Boc-tyr-tyr-OMe 2, Boc-pro-val-OMe 3 and a single amino acid methyl ester hydrochloride unit, pro-OMe-HCl 4. The required dipeptides were prepared by coupling Boc amino acids with the respective amino acid ester hydrochlorides using DIPC, CHCl₃ and N-methyl morpholine according to Bondanszky [8] procedure with suitable modifications. The Boc-group of the dipeptide 2 was removed by using trifluoroacetic acid and the ester group of dipeptide 1 was removed by using LiOH. The deprotected units were then coupled to get a tetrapeptide Boc-gly-tyr-tyr-tyr-OMe 5. Similarly, the dipeptide 3 was coupled with single amino acid methyl ester hydrochloride unit, pro-OMe HCl ₄ after appropriate deprotection to get a tripeptide Boc-pro-val-pro-OMe 6. The resulting tetrapeptide and tripeptide was then coupled together by using DIPC, NMM and CHCl₃ to get a linear heptapeptide Boc-gly-tyr-tyr-tyr-pro-val-pro-OMe 7. Finally cyclisation of this linear heptapeptide was carried out by p-nitrophenyl ester method. The intermediates and the final product were purified by recrystallisation from CHCl₃. The retrosynthetic analysis of peptide is shown in the Scheme 1.

The newly synthesized compound was analyzed for C, H, N, and O by elemental analysis and structure was confirmed by IR, ¹H NMR and FAB mass spectral analysis. The characteristic IR absorption bands of -CO-NH- moiety was present in the cyclised product. The NMR spectrum of cyclised product clearly indicates the presence of all respective amino acid moieties. Furthermore, the mass spectrum of this cyclic heptapeptide showed a molecular ion peak at m/z 840, which corresponds to molecular formula C₄₄H₅₃O₁₀N₇.

The synthesized cyclic heptapeptide was screened in vitro for its antibacterial and antifungal activity by using disc diffusion method and tube dilution technique. The antibacterial activity was determined against four bacterial species (B. subtilis, S. aureus, E. coli and P. aeruginosa) and antifungal activity against Candida albican. In the disc diffusion method, the activity studies were carried out according to modified Kirby-Bauer method [9]. Benzyl penicillin and fluconazole were used as standards against bacterial and fungal strains, respectively at a concentration of 50 µg/ml. Nutrient broth and Sabourds agar were used as a medium and dimethylformamide (DMF) was used as a solvent control for carrying out the activity. After preparation of the disc, allowed to stand for 24 h at 370. The zone of inhibition, observed around the disks after incubation, was measured. The synthetic peptide has shown moderate activity against B. subtilis and S. aureus (gram positive bacteria) and less activity against E. coli and P. aeruginosa (gram negative bacteria) when compared with standard drug benzyl penicillin. The compound has also shown moderate inhibition of growth against Candida albicans.

Figure 1:Synthetic route for the synthesis of delavayin-C.
a= DIPC, NMM, CHCl₃, RT, 24 h, b= TFA, NMM, RT, 1 h, c= LiOH, THF:H₂O (1:1), reß ux, 15 mins, d= pnp-, CHCl₃, RT, 12 h, e= NMM,CHCl₃, 0ºC, 7 d.

Compound inhibiting growth of microorganisms was further tested for minimum inhibitory concentration (MIC). A solution of the compound was prepared in DMF and a series of doubling dilutions prepared with sterile pipettes. To each of a series of sterile stoppered test tubes, a standard volume of nutrient broth medium was added. A control tube containing no antimicrobial agent was included. The inoculum consisting of an overnight broth culture of microorganisms was added to separate tubes. The tubes were incubated at 370 for 24 h and examined for turbidity. The tube with highest dilution showing no turbidity was the one containing compound with MIC. Screening data of antibacterial and antifungal activity revealed that the synthetic peptide is found to be active. The results are shown in Tables 1 and 2.

Melting points were taken in open capillary tubes and are found to be uncorrected. IR spectra was recorded on Jasco FTIR 5300 IR spectrometer (in CHCl₃) and the chemical shift values are reported as values as Vmax (cm^-1). ¹H NMR spectra was recorded on Brucker AC NMR spectrometer (300 MHZ in CDCl₃) and the chemical shift values are reported as values in ppm relative to TMS (δ=0) as a internal standard. FAB mass spectra were recorded on a Joel SX 102/ DA-6000 Mass Spectrometer using xenon as a carrier gas. TLC was done to check the progress of reaction by using silica gel-G plates. All the compounds gave satisfactory elemental analysis for C, H, N and O.

Table 2: Minimum Inhibitory Concentration For Antimicrobial Activity.

Table 2: Minimum Inhibitory Concentration For Antimicrobial Activity.

The dipeptides 1 and 2 were used for the preparation of a tetrapeptide Boc-gly-tyr-tyr-tyr-OMe (5). The tripeptide Boc-pro-val-pro-OMe (6) was prepared by coupling a dipeptide Boc-pro-val-OMe (3) with pro-OMe HCl (4) unit. The resulting tetrapeptide and tripeptide were coupled by using DIPC and N-methyl morpholine (NMM) to obtain a linear heptapeptide Boc-gly-tyr-tyr-tyr-pro-val-pro-OMe (7). Cyclisation of this linear heptapeptide was carried out by using p-nitrophenyl ester method [10]. The ester group of the linear segment was removed with LiOH and the p-nitrophenyl ester group was introduced using the following procedure, The Boc-peptide carboxylic acid (1.5 mmol) was dissolved in CHCl3 (15 ml) at 00. Then p-nitrophenol was added (0.27 g, 2 mmol), and stirred for 12 h at room temperature. The reaction mixture was filtered and the filtrate was washed with NaHCO₃ solution (10%) until excess of p-nitrophenol was removed and finally washed with 5% HCl (5 ml) to get Boc-peptide-pnp-ester.

To the above Boc-peptide-pnp-ester (1.2 mmol) in CHCl₃ (15 ml), CF₃COOH (0.274 g, 2.4 mmol) was added, stirred for 1 h at room temperature and washed with 10% NaHCO₃ solution. The organic layer was dried over anhydrous Na₂SO₄. To the Boc-deprotected peptide-pnp-ester in CHCl₃ (15 ml), N-methylmorpholine (1.4 ml, 2 mmol) was added and kept at 00 for 7 d. The reaction mixture was washed with 10% NaHCO₃ until the byproduct p-nitrophenol was removed completely and finally washed with 5% HCl (5 ml). The organic layer was dried over anhydrous Na₂SO₄. Chloroform and pyridine were distilled off to get the crude product of cyclized compound, which was then recrystallized from CHCl₃/n-hexane.

Physical state was found to be semisolid mass, molecular formula is C₄₄H₅₃O₁₀N₇ with a molecular weight of 839. Rf value was found to be 0.60 in the solvent system, chloroform:methanol:water (5:3:2). IR data is 3676.4 (OH stretch), 3293.1 (NH stretch), 3017.8 (Arom-CH stretch), 2935.2 (aliph-CH stretch), 2857.8 (aliph-CH stretch), 1658.7 (C=O stretch of amide), 1530.4 (OH-bend) 1451.5 (NH bend) cm-1. 1H NMR data was δ 10.3 (3H, d, NH), 8.1 (2H, d, NH), 7.65-6.7 (12H, m, Arom-H), 4.9 (1H, d, α-H), 4.7 (1H, d, α-H), 4.55 (2H, m, α-H), 4.4 (1H, m, α-H), 4.2 (1H, m, α-H), 4.0 (1H, m, α-H), 3.9 (1H, m, α-H), 3.7 (4H, m, NCH₂ of Pro), 3.5 (10H, m, β-CH₂ of tyr and β-CH₂ of pro), 2.3 (1H, m, β-H of val), 0.95 (6H, d, (CH₃)₂ of val. Molecular ion peak observed at m/z 840 corresponds to the molecular formula C₄₄H₅₃O₁₀N₇ . C: 63.1 (62.92)%, N: 12.16 (11.67)%.

Results of biological activity were shown in Tables 1 and 2. The newly synthesized compounds showed significant antibacterial activity against gram positive bacteria in comparison to the standard drug benzyl penicillin. It has also shown moderate antifungal activity in comparison with the standard drug fluconazole.

Acknowledgements

The authors are thankful to N. G. S. M. Institute of Pharmaceutical sciences, Mangalore for providing the facilities to carry out the research work. We wish to extent our thanks to CDRI Lucknow, SAIF staff, Panjab University and IICT Hyderabad for spectral and elemental analysis.

References

1. Tsutomu P, Ishiyama D, Honda R, Senda H, Konno H, Tokumasu S.Antifungal cyclic depsipeptide-Glomosporin. J Antibiot 2000;53:597.
2. Pettit GR, Feng G, Carny RL, Larry PT, Schmidt JM. Isolation andstructure of Axinastatins 2 and 3 from a western caroline Island Marinesponge. J Med Chem 1994:37.
3. Jioji NT, Linda AM, Kettenesvan JJ. Jaspars M. Axinellin-C, a prolinerich cyclic octapeptide isolated from the Fijian marine sponge stylotellaaurantium. J Am Chem 2002;23:584-79.
4. Morita H, Yoshida N, Tekeya K, Itakova H, Shirota O. AngiotensinConverting enzyme inhibitors-Lyciumins A&B. Tetrahedron 1996:52
5. Sakayi Y, Yoshida T, Sujita T, Ochiai K, Agatsuma T. Isolationof Cyclic hexadepsipeptide antitumor antibiotic GE 3. J Antibiot1997;50:659.
6. Dathe M, Nikolenko H, Klose J, Bienert M. Cyclization increases theantimicrobial activity and selectivity of arginine trypotophan containinghexapeptides. Biochemistry 2004;43:9140.
7. Hiroshi M, Takashi K, Uchida A, Takeya K, Itokawa H. Cyclic peptidesfrom higher Plants Delavayin A-C. J Nat 1997;60:212-15.
8. Bodanszky M, Bodanszky A. Practice of peptide synthesis. New York:Springer-verlog Publishers; 1984.p.143.
9. Bauer AW, Kirby WMA, Sherris JC, Truck M. Antibiotic susceptibilitytesting by a standardized single disk method. Am J Clin path1996;45:493-6.
10. Bodanszky M, Bodanszky A. Cyclization of linear peptide by usingp-nitrophenyl ester method. Practice of peptide synthesis. New York:Springer-Verlog; 1984.p.78
